ENGINE |
Engine |
Tata 4SPCR |
Engine Capacity (cc) |
2956 |
Power (HP @ rpm) |
85 @ 2800 |
Torque (Nm @ rpm) |
250 @ 1400-2400 |
Emission Norm |
BS IV |
TRANSMISSION AND STEERING |
Clutch |
Single plate dry friction type |
Clutch Dia (mm) |
280 |
Gearbox |
GBS-380; 5F+1R |
Steering |
Power Steering |
FRAME & SUSPENSION |
Frame Type |
Ladder type frame with riveted/ bolted cross members |
Front Suspension |
Semi-elliptical leaf springs |
Rear Suspension |
Semi-elliptical leaf springs |
BRAKES |
Service Brakes |
Vacuum assisted dual circuit hydraulic |
WHEELS & TYRES |
Tyre Size |
8.25 x 16 -16 PR |
DIMENSIONS |
WB (mm) |
3305 |
Overall length (mm) |
|
TCD (m) |
13.1 |
Ground Clearance (mm) |
249 |
WEIGHTS |
GVW (kgs) |
5300 |
Kerb Weight (kgs) |
2200 |
OTHERS |
Gradeability (%) |
23 |
Fuel Tank (ltr) |
60 |
